130 Dc Electric Motor Small 6v DC Motor 30000RPM Customized Shaft Brushed Motor
-
Name130 Small Hobby Electric Motors
-
Motor TypeFC-130
-
Direction Of RotationCW/CCW
-
Motor CategoryDual Shaft Electric Motor
-
Rated Volt6V DC
-
No-load Speed20000±200rpm
-
Motor Shaft Diameter2mm
-
Motor Size25mm*20mm (L*Dia)
-
ApplicationsHobby Model/Electric Toy Car/Arduino Toys
-
Stall Torque≥80g-cm
-
Place of OriginDongguan,China
-
Brand NameLihua Motor/HCS Motors
-
CertificationReach/RoHs/IATF16949/ISO9001
-
Model NumberFC-130 Size Motor
-
Minimum Order Quantity1000PCS
-
PriceNegotiation
-
Packaging DetailsCarton
-
Delivery Time35-45Day
-
Payment TermsL/C,D/A,D/P,T/T,L/C,D/A,D/P,T/T,Western Union,MoneyGram
-
Supply Ability10000PCS/Day
130 Dc Electric Motor Small 6v DC Motor 30000RPM Customized Shaft Brushed Motor
130 Dc Electric Motor Small 6v DC Motor 30000RPM Customized Shaft Brushed Motor
Standard '130 size' DC hobby motors are what these are. Compared to other toy motors, they have a greater functioning range, ranging from 1V to 12VDC rather than 3.0-6.0V. Since you are more likely to have 5 or 9V available than a high current 3V setting, this range makes them ideal for controlling with an Adafruit Motor Shield or an Arduino. Most electronics that currently have 130-size motors installed can accommodate them, and two wires that are compatible with breadboards have already been soldered on for quick prototyping.
FC-130 DC Electric Motor Small Size Key Features
- Motor Name/Type:FC-130 micro motor
- Suitable voltage: DC 3.0V-12.0V
- Rated Voltage: 3.0VDC/3.7.0VDC/5.0VDC/6.0VDC/12.0VDC
- Body Size: 27.5mm x 20mm x 15mm
- Shaft Size: 8mm x 2mm diameter
- Operating Temperature: -10°C ~ +80°C
- Direction of Rotation:CCW/CW
- Protect Feature:Totally Enclosed
- Commutation:Brush
- Use:BOAT, Car, Electric Bicycle, FAN, Home Appliance, SMART HOME, Robot
- Test data:
- Voltage:3.0V No-load current≤160mA No-load speed:8300RPM
- Voltage:3.7V No-load current≤175mA No-load speed:10250RPM
- Voltage:5.0V No-load current≤185mA No-load speed:14200RPM
- Voltage:6.0V No-load current≤350mA No-load speed:20000RPM
- Voltage:12.0V No-load current≤30mA No-load speed:7500RPM
- *Note:lt's only typical technical data for reference, special requirement can be customized.
-
Custom Service:
As a manufacturer and trader with product certifications, we offers quality control services and full customization options including design and sample tailoringto meet diverse client requirements.
130 Size Adafruit Motor Dimensions
Standard 130 Size Arduino Motor Parameter/Specification
1.Motor Size:20mm*25mm*15mm
2.Motor Shaft Length:9.4mm (Custom Options)
3.Motor Diameter:2mm
4.Bearing Outside Diameter:6.15mm
5.Bearing Hight:1.7mm
6.130 total length:38mm
NOTES: We accpted motor size customization ,all size can be designed as your need.
