GM25-320 25mm Gear Reduction Motor Customize 70RPM 10kgf.cm For Paper Dispenser

GM25-320 25mm Gear Reduction Motor Customize 70RPM 10kgf.cm For Paper Dispenser

he GM25-320 DC Gear Motor is a highly customizable and efficient motor solution, designed to meet specific needs in applications such as paper dispensers. With a compact 25mm diameter, this motor is powered by a 320 micro motor combined with a precision gear reduction box, offering customizable reduction ratios of 29:1, 31:1, 78:1, 195:1, and 488:1. Customers can tailor the motor's speed, voltage, current, output shaft length, and shape (round/D-shape) to fit their unique design requirements.

Delivering up to 10kgf.cm of torque at a speed of 70RPM, the GM25-320 motor is engineered for reliable low-speed, high-torque performance, making it ideal for paper dispensing systems. The adjustable features of this motor allow for seamless integration into various paper dispenser designs, ensuring smooth and precise operation for continuous paper dispensing tasks.

Whether used in office equipment, automated paper roll systems, or other related applications, the GM25-320 offers a dependable solution with customizable options to meet performance and integration demands. Its adaptability, compact design, and high torque output make it a perfect choice for applications requiring controlled, high-torque rotation.

Model : GM25-320 /GA25Y320  micro metal gearmotor

Gearbox: 25 mm Dia metal spur gear reducer

Motor Size:20mm*L (Motor Length can be custom )

Shaft : Φ4mm D-cut 0.5mm, M4, custom

Gear Box Size:25mm*H mm (Gearbox Size can be custom)
Shaft size : Approx. 4 x L mm (Dia.*L)
Nominal Voltage : DC 3V 6V 12V 36V

Operating Voltage:3V-9V 12V-24V 18V-26V
Revolving speed:
10RPM/15 RPM / 50 RPM / 75 RPM / 100 RPM / 125 RPM / 150 RPM / 200 RPM / 250 RPM / 500 RPM
3V : 25 RPM / 1000 RPM
6V : 30 RPM / 400 RPM / 1000 RPM / 2000 RPM
12V : 60 RPM / 300 RPM / 400 RPM / 800 RPM / 1000 RPM / 2000 RPM / 4000 RPM

Encoder : Magnetic encoder available;
Commutation: Carbon brush/Graphite brush/Metal brush;
Construction: micro Permanent Magnet iron cored dc electric motor

GM25-320 25mm Gear Reduction Motor Features and Custom Service

3V–24V Mini 25mm Gearbox 320 Motor Parameter List & Dimensions

Model: GA25-320,3V 6V 12V DC Gear Motor Paramter List

Note: all reduced no-load speeds have a tolerance of ±15%.
